A170-Plunger Pump-Wuxi Haiyan High-pressure Valve Factory

A170

Stroke Length (mm) ：170
Crankcase Oil Capacity (L)：120
Pump Weight (KG)： 4830
Recommended SPM for Continuous Duty： ≤246

	Strokes per Minute	75	83	93	106	119	133	149	166	186	210	237
	Input Power (kw)	114.4	126.6	141.9	167.7	181.6	202.9	227.3	254.4	283.8	320.	361.6
Plunger Size(mm)	Rated Pressure(bar)	Rated Capacity(L/min)
70	416	147.2	162.9	182.5	208.0	233.6	261.0	292.4	325.8	365.1	412.2	600.8
75	362	169.0	187.0	209.5	238.8	268.1	299.7	335.7	374.0	419.1	473.2	465.2
80	318	192.3	212.8	238.4	271.7	305.1	341.0	382.0	425.5	476.8	538.3	534.0
85	282	217.1	240.2	269.1	306.8	344.4	384.9	431.2	480.4	538.3	607.7	607.6
90	252	243.3	269.3	301.7	343.9	386.1	431.5	483.4	538.6	603.5	681.3	685.9
95	226	271.1	300.0	336.2	383.2	430.2	480.8	538.6	600.1	672.4	759.1	768.9
100	204	300.4	332.5	372.5	424.6	476.7	532.7	596.8	664.9	745.0	841.2	856.8
105	185	331.2	366.5	410.7	468.1	525.5	587.3	658.0	733.1	821.4	927.4	949.3
110	168	363.5	402.3	450.7	513.8	576.8	644.6	722.2	804.6	901.5	1017.8	1046.6
115	154	397.3	439.7	492.7	561.5	630.4	704.5	789.3	879.4	985.3
120	141	432.6	478.7	536.4	611.4	686.4	767.1	859.4	957.5	1072.8
125	130	469.4	519.5	582.1	663.4	744.8	832.4	932.5	1038.9
130	121	507.7	561.9	629.6	717.6	805.6	900.3	1008.6
135	112	547.5	605.9	773.8	868.7	868.7	970.9

Strokes per Minute

106

119

133

149

166

186

210

237

Input Power (kw)

114.4

126.6

141.9

167.7

181.6

202.9

227.3

254.4

283.8

320.

361.6

Plunger Size(mm)

Rated Pressure(bar)

Rated Capacity(L/min)

416

147.2

162.9

182.5

208.0

233.6

261.0

292.4

325.8

365.1

412.2

600.8

362

169.0

187.0

209.5

238.8

268.1

299.7

335.7

374.0

419.1

473.2

465.2

318

192.3

212.8

238.4

271.7

305.1

341.0

382.0

425.5

476.8

538.3

534.0

282

217.1

240.2

269.1

306.8

344.4

384.9

431.2

480.4

538.3

607.7

607.6

252

243.3

269.3

301.7

343.9

386.1

431.5

483.4

538.6

603.5

681.3

685.9

226

271.1

300.0

336.2

383.2

430.2

480.8

538.6

600.1

672.4

759.1

768.9

100

204

300.4

332.5

372.5

424.6

476.7

532.7

596.8

664.9

745.0

841.2

856.8

105

185

331.2

366.5

410.7

468.1

525.5

587.3

658.0

733.1

821.4

927.4

949.3

110

168

363.5

402.3

450.7

513.8

576.8

644.6

722.2

804.6

901.5

1017.8

1046.6

115

154

397.3

439.7

492.7

561.5

630.4

704.5

789.3

879.4

985.3

120

141

432.6

478.7

536.4

611.4

686.4

767.1

859.4

957.5

1072.8

125

130

469.4

519.5

582.1

663.4

744.8

832.4

932.5

1038.9

130

121

507.7

561.9

629.6

717.6

805.6

900.3

1008.6

135

112

547.5

605.9

773.8

868.7

970.9
